034 Motorsport B9/B9.5 Audi RS4/RS5 EA839 2.9TT Dynamic+ Performance ECU & AL552 ZF8 Transmission Tuning Bundle
- Description
- Fitment
- Refund Policy
Dynamic+ Performance Tuning
The 034Motorsport Dynamic+ ECU & TCU Tuning Bundle is engineered to transform the driving experience of the Audi EA839 2.9T platform. By optimizing engine calibration and transmission behavior together, Dynamic+ Tuning delivers significant improvements in power delivery, responsiveness, and overall vehicle performance.
Unlike generic calibrations that focus solely on peak dyno numbers, Dynamic+ Tuning is developed and validated through extensive real-world testing to ensure consistent performance in all driving conditions. From daily commuting to spirited canyon driving and track use, every calibration is designed to maximize performance without sacrificing refinement.
Whether you are looking for a refined daily driver or a fully optimized performance setup, Dynamic+ Tuning delivers OEM-level integration with substantial performance gains.
Why Choose Dynamic+?
034Motorsport Dynamic+ Tuning is developed through extensive real-world street and track testing to deliver OEM-like drivability with significantly enhanced performance. Each calibration is engineered to provide refined part-throttle behavior, predictable power delivery, and increased acceleration and responsiveness on both pump fuel and ethanol blends.
Dynamic+ ECU and TCU calibrations are developed together to ensure proper torque management, seamless drivability, and optimized transmission behavior across every driving mode. With support for multiple octane files and mobile flashing through the 034SPI App, Dynamic+ Tuning delivers a refined and flexible performance solution for every type of enthusiast.
034MOTORSPORT EA839 2.9TT TURBOCHARGED PERFORMANCE SOFTWARE DYNO CHARTS:
Select Dyno Chart:
034MOTORSPORT EA839 2.9TT TURBOCHARGED PERFORMANCE SOFTWARE COMPARISON:
| Stage | Fuel | Max HP | Max TQ | Max HP Gain | Max TQ Gain | Rev Limiter* | Speed Limiter |
|---|---|---|---|---|---|---|---|
| Stock | 91 Oct (AKI) | 441 HP | 467 TQ | NA | NA | 6,800 RPM | 155 MPH |
| Stage 1/2 | 91 Oct (AKI) | 484 HP | 501 TQ | 48 HP @ 6,300 RPM | 41 TQ @ 6,300 RPM | 7,200 RPM | ∞ |
| Stage 1/2 | 93 Oct (AKI) | 514 HP | 537 TQ | 71 HP @ 6,300 RPM | 78 TQ @ 3,550 RPM | 7,200 RPM | ∞ |
| Stage 1/2 | E85 | 532 HP | 548 TQ | 91 HP @ 5,300 RPM | 84 TQ @ 5,500 RPM | 7,200 RPM | ∞ |
| Stage 1+/2+ | 91 Oct (AKI) | 484 HP | 501 TQ | 48 HP @ 6,300 RPM | 41 TQ @ 6,300 RPM | 7,200 RPM | ∞ |
| Stage 1+/2+ | 93 Oct (AKI) | 514 HP | 537 TQ | 71 HP @ 6,300 RPM | 78 TQ @ 3,550 RPM | 7,200 RPM | ∞ |
| Stage 1+/2+ | E85 | 566HP | 610 TQ | 132 HP @ 6,300 RPM | 151 TQ @ 3,600 RPM | 7,200 RPM | ∞ |
| Stage 3 | 91 Oct (AKI) | 536 HP | 546 TQ | 87 HP @ 6,400 RPM | 94 TQ @ 4,000 RPM | 7,200 RPM | ∞ |
| Stage 3 | 93 Oct (AKI) | 590 HP | 596 TQ | 135 HP @ 6,400 RPM | 147 TQ @ 4,200 RPM | 7,200 RPM | ∞ |
| Stage 3 | E85 | 680 HP | 665 TQ | 235 HP @ 6,400 RPM | 211 TQ @ 4,000 RPM | 7,400 RPM | ∞ |
| Stage 3 | E60-E70 | 713 HP | 679 TQ | 267 HP @ 6,400 RPM | 151 TQ @ 4,300 RPM | 7,400 RPM | ∞ |
| Stage 3 RS+ | E85 | 713 HP | 679 TQ | 267 HP @ 6,400 RPM | 151 TQ @ 4,300 RPM | 7,400 RPM | ∞ |
***All octane ratings are in US standard AKI (RON+MON). Some ROW countries such as the UK use a RON octane rating that differs from US Octane ratings. Please email tuning@034motorsport.com to ensure you are running the correct octane file for your area. Running the incorrect octane file for your fuel can result in irreversible damage.
Dynamic+ ECU Breakdown
Dynamic+ ECU Tuning is available in multiple stages to support everything from completely stock vehicles to fully built ethanol-powered hybrid turbo setups. Each calibration is designed around specific hardware configurations to maximize performance while maintaining proper safety strategies, drivability, and reliability.
Stage 1 ECU
Stage 1 is designed for completely stock vehicles and requires no hardware modifications. Optimized boost, ignition timing, and torque calibration unlock substantial power gains while maintaining excellent street manners and factory-like drivability.
For most owners, Stage 1 delivers the single largest improvement in overall performance, transforming the driving experience with significantly increased horsepower, torque, and throttle response while retaining the comfort and refinement expected of a daily-driven Audi. Every calibration is developed with engine safety and long-term reliability as primary objectives, utilizing comprehensive data analysis, rigorous dyno development, and thousands of miles of real-world street testing across a wide range of climates, elevations, fuel qualities, and driving conditions. 034Motorsport Calibrators verify every aspect of the tune, from boost control and ignition timing to fuel delivery, knock control, and thermal management, ensuring smooth, repeatable performance with factory safeguards operating as intended.
Rather than simply increasing peak power, 034Motorsport Calibrators carefully recalibrated the entire powerband to provide stronger acceleration throughout the rev range, resulting in a vehicle that feels more responsive in everyday driving as well as under full throttle. Cold starts, idle quality, part-throttle cruising, and overall drivability emulate an OEM+ level of refinement, making Stage 1 the ideal starting point for enthusiasts looking to extract substantial performance gains without requiring any supporting hardware.
Stage 2 ECU (Included with Stage 1 ECU)
Throughout our rigorous software development process, we evaluated the conventional Stage 2 hardware configuration of high-flow downpipes paired with the factory turbochargers to determine whether meaningful performance gains could be achieved over our Stage 1 and Stage 1+ calibrations. Across all fuel types tested, our engineers found that the OEM downpipes provided sufficient exhaust flow for the factory turbochargers, and that installing a more free-flowing exhaust system did not result in additional horsepower or torque gains.
While our data-driven approach initially led us to focus exclusively on the configurations that delivered measurable performance improvements, customer demand for downpipe-compatible calibrations continued to grow. In response, 034Motorsport offers Stage 2 and Stage 2+ ECU files for the B9/B9.5 Audi RS4 and RS5, specifically designed to support vehicles equipped with high-flow catted or catless downpipes, without visible error codes.
These calibrations provide seamless compatibility with these hardware configurations while retaining the drivability, refinement, and OEM safety strategies expected from Dynamic+ Tuning. Stage 2 and Stage 2+ ECU files are included with the purchase of Stage 1 or Stage 1+ ECU Tuning at no additional cost, giving you the flexibility as your vehicle evolves.
Stage 1+ & 2+ Add-On
Looking to maximize performance on E85? With the installation of the 034Motorsport Upgraded High Pressure Fuel Pump Piston Upgrade and Stage 1+/2+ calibration, you can unlock an additional 34+hp and 62+tq over standard Stage 1/2 E85 power figures! The Upgraded HPFP allows for additional fuel flow that the factory fueling system lacks to fully maximize E85 power potential. We highly recommend this upgrade for anyone that primarily aims to enjoy the fruits of the ethanol juice!
Stage 2 & Stage 2+ calibrations are for Sanctioned Racing Use only
|
Stage 1 Features
|
Stage 2 Features
|
Stage 3 ECU
Stage 3 ECU Tuning is designed for enthusiasts ready to take their B9/B9.5 Audi RS4 or RS5 to the next level with TTE720 hybrid turbochargers, along with key supporting hardware upgrades. Delivering truly visceral acceleration and relentless power throughout the rev range, Stage 3 transforms the driving experience into something far beyond what the factory turbochargers can achieve. Extensive calibration changes allow the EA839 2.9T platform to fully utilize the increased airflow capacity of these hybrid turbochargers while preserving the smooth drivability, comprehensive OEM safety strategies, and reliability expected from a thoroughly engineered 034Motorsport calibration. Every file is developed through rigorous dyno testing, comprehensive data analysis, and extensive real-world validation to ensure repeatable performance, effective thermal management, and dependable operation in even the most demanding driving conditions.
Rather than simply maximizing peak horsepower, 034Motorsport Calibrators optimized every aspect of the calibration, including boost control, ignition timing, fueling, torque modeling, throttle mapping, and turbocharger operation, to deliver predictable, repeatable performance throughout the entire powerband. Stage 3 includes pump fuel calibrations along with E60-E70 and Full E85 files that intentionally provide additional fueling and thermal headroom while still delivering exceptional performance. By operating with an increased safety margin, these calibrations are ideal for customers seeking an outstanding balance of power, long-term reliability, and repeatable performance under demanding driving conditions.
Stage 3 RS+ ECU
For customers looking to prioritize Ethanol performance and maximize fuel system headroom, the Stage 3 RS+ calibration is available exclusively for TTE720 vehicles equipped with the 034Motorsport RS+ Injectors. The additional fueling capacity provided by the RS+ Injectors enables the engine to achieve the same Stage 3 E60-E70 power output while operating on full E85, eliminating the need to blend fuel to an E60-E70 mixture.
Stage 3 Features
- All Stage 1 & Stage 2 Features
- Designed for TTE720 hybrid turbocharger upgrade (see required hardware here)
- Comprehensive ECU remodeling for hybrid turbocharger operation
- Optimized boost, airflow, fueling, and ignition control
- Increased horsepower and torque throughout the rev range
- Significantly enhanced top-end performance
- Refined safety protocols for reliable performance under extreme conditions
- Optimized boost and fueling targets with increased thermal and fueling headroom
- Extensive dyno, street, and real-world validation
- VariSpec Adjustable Features Enabled
Stage 3 RS+ Features
- All Stage 1, 2, & 3 Features
- Requires 034Motorsport RS+ Injector Upgrade Kit
- Supports full E85 operation
- Increased fueling capacity and safety margin
- Maximized ethanol performance potential
- Exclusive ECU calibrations developed specifically for RS+ Injectors
- Highest-output Dynamic+ ECU calibration available
- VariSpec Adjustable Features Enabled
Dynamic+ AL552 ZF8 Transmission Tuning
TCU Matters Too
The AL552 ZF8 Transmission is an integral part of the performance equation. Dynamic+ TCU Tuning recalibrates shift behavior, torque management, launch strategies, and gear selection logic to fully complement ECU tuning and unlock the transmission's true capability.
Whether paired with Stage 1 ECU Tuning or a fully-built Stage 3 RS+ setup, Dynamic+ TCU calibrations improve shift quality, increase responsiveness, and optimize performance throughout the entire operating range.
For 2022+ vehicles equipped with factory-locked transmissions, 034Motorsport offers the Boot Loader Unlock (BLU) Harness, which enables secure unlocking of the TCU for flashing. Once unlocked, customers can take full advantage of Dynamic+ TCU tuning, including expanded calibration control and transmission-level performance optimization that cannot be achieved with ECU-only solutions.
Stage 1 TCU
Stage 1 TCU Tuning is designed to complement Dynamic+ ECU Tuning by unlocking the transmission's full torque capacity while optimizing torque management, shift quality, and transmission behavior. The ECU Tuning accurately reports engine torque to the TCU, allowing both control units to communicate seamlessly while preserving factory safety strategies.
By properly calibrating the transmission to manage the increased torque output, Stage 1 TCU eliminates unnecessary torque intervention, improves shift consistency, and delivers smoother, quicker shifts with more confident power transfer.
Stage 1 Features
- Improved shift quality and consistency
- Optimized torque intervention strategies
- Enhanced drivability in all driving modes
- Correct torque modeling and reporting
- Improved transmission responsiveness
- Maintains factory safety systems
Stage 2 TCU
Stage 2 TCU Tuning is the definitive transmission upgrade for enthusiasts looking to unlock the full performance potential of their EA839-powered Audi. Building upon the foundation of Stage 1, Stage 2 delivers dramatically faster, firmer shifts, optimized shift points, improved launch control, and a significantly more engaging driving experience. Every shift is calibrated to keep the engine in its optimal powerband, resulting in quicker acceleration, sharper responsiveness, and a transmission that feels purpose-built for spirited street driving, canyon roads, and track use. Stage 2 TCU Tuning is the recommended transmission calibration for both Stage 1 and Stage 2 Dynamic+ ECU Tuning.
Stage 2 Features
- All Stage 1 TCU Features
- Compatible with Stage 1/1+ and Stage 2/2+ ECU Tuning
- Faster shift execution
- Optimized shift points
- Improved launch control performance
- AMAX launch shifting enabled for 1st through 6th gear
- Increased transmission responsiveness
- No hardware upgrades needed
- VariSpec Adjustable Features Enabled
Stage 3 TCU
Stage 3 TCU Tuning is specifically optimized for Stage 3 & Stage 3 RS+ ECU calibrations. Revised shift points and gear selection strategies help keep upgraded turbochargers operating within their most effective power range for maximum acceleration and performance.
Stage 3 Features
- All Stage 1 & 2 TCU Features
- Optimized shift points for hybrid turbocharger applications
- Improved acceleration performance
- Enhanced launch and shift strategies
- Designed specifically for Stage 3 ECU calibrations
- Maximizes utilization of the upgraded turbocharger powerband
- VariSpec Adjustable Features Enabled
VariSpec
Make It Yours
034Motorsport VariSpec is a feature customization suite within 034SPI, giving you direct control over market-first features and functionalities within your tunes. Instead of being locked into a single feature set, VariSpec lets you tailor key performance and drivability features to your hardware, driving style, and personal preferences.
With VariSpec on your B9/B9.5 RS4 or RS5, you can configure multiple features under various modules:
Exhaust
Crackle Overrun
Fine-tune your crackle overrun exactly how you want it. Enable or disable crackles entirely, or independently adjust:
- Duration from 1 second up to 2.5 seconds
- Aggressiveness with five selectable intensity levels
- Pattern to control firing frequency and overall crackle character
From subtle pops to an aggressive motorsport-inspired sound, the choice is yours.
Exhaust Flap Control
Customize factory exhaust valve behavior with multiple operating modes:
- Factory
- Dynamic+ Optimized
- Always Open
- Valveless Exhaust Mode for aftermarket exhaust systems without exhaust valves
Catalyst Heating Control (Stage 2/2+ & Stage 3/3 RS+ Only)
Enable or disable the factory catalyst heating routine (cold-start high idle) to tailor startup behavior to your preference.
For Sanctioned Racing Use Only.
Engine
Top Speed Limiter
Choose between the factory speed limiter and an unrestricted top speed.
Auto Start/Stop Control
Configure how the factory Auto Start/Stop system operates:
- Factory Behavior
- Default Off
Built Engine Mode
Designed specifically for compatible 034Motorsport Built Engine packages, this option applies the necessary calibration changes to support upgraded engine components.
Warm Idle Target
Increase warm idle speed to 900 RPM to reduce noise, vibration, and harshness (NVH) when using upgraded engine or transmission mounts.
Stock TCU Performance Patch
For late-model vehicles equipped with locked or untuned factory transmissions, this feature safely enables the full torque output of your Dynamic+ ECU Tune without requiring TCU tuning.
While the Stock TCU Performance Patch provides a safe and effective solution for ECU-only setups, full transmission tuning is strongly recommended to unlock the full performance, drivability, and shift-quality improvements. A properly calibrated TCU tune enhances shift speed, optimizes shift logic under load, improves torque management, and delivers a more cohesive overall driving experience when paired with ECU tuning.
Drivetrain
Left Foot Braking
Enable simultaneous brake and throttle input for brake boosting and trail braking during performance driving.
Track use only.
Transmission
Rolling KLi-MAX
Enables AMAX-based high-performance shift strategy during rolling acceleration in Sport and Manual modes for faster, more direct shifts under load above approximately 5,500 RPM.
Launch Grip
For vehicles with high-grip tires or drag racing on a prepped surface, enabling High Grip increases the torque applied in 1st gear when using launch control.
Gear Display
Displays the current gear in the instrument cluster.
Wireless ECU & TCU Flashing
Flash anywhere.
No laptop required.
Connect via Bluetooth to the Dynamic+ R4 Dongle and upload your tune directly from your phone or tablet — flash ECU and TCU software without touching a PC.
What it does
Everything you need,
from your phone
034SPI pairs with the Dynamic+ R4 Flashing Dongle via Bluetooth to deliver a full suite of tuning, monitoring, and diagnostic tools — no Windows PC, no cables, no shop visit needed.
Requires Dynamic+ ECU or TCU tune and the R4 Dynamic+ End User Flashing Dongle (May 2023 or newer, USB-C). Compatible with iOS, Android, and Apple Silicon Macs (M1/M2/M3/M4). Older USB-B R3 dongles are not supported by 034SPI.
For those with Windows 10/11 PC’s and/or an older R3 Flashing Cable, our Windows-Based 034SPI Flashing Client can be downloaded here.
Stage 1 & 2 ECU Tune Supporting Modification Requirements:
| Part Upgrade | Stage 1 ECU | Stage 1+ ECU | Stage 2 ECU | Stage 2+ ECU |
|---|---|---|---|---|
| Intake | Recommended | Recommended | Recommended | Recommended |
| Intercooler | Recommended | Recommended | Recommended | Recommended |
| Downpipes | Not Compatible | Not Compatible | Required | Required |
| Upgraded HPFP | Not Required | Required | Not Required | Required |
| Ethanol Content Sensor | Recommended (for Ethanol Files) | Recommended (for Ethanol Files) | Recommended (for Ethanol Files) | Recommended (for Ethanol Files) |
| Stage 1 TCU | Recommended | Recommended | Recommended | Recommended |
| Stage 2 TCU | Recommended | Recommended | Recommended | Recommended |
Stage 3 & 3 RS+ ECU Tune Supporting Modification Requirements:
| Part Upgrade | Stage 3 TTE720 ECU | Stage 3 RS+ TTE720 ECU |
|---|---|---|
| Intake | Required | Required |
| Intercooler | Required | Required |
| Downpipes | Required | Required |
| Upgraded HPFP | Required | Required |
| Ethanol Content Sensor | Recommended (for Ethanol Files) | Recommended (for Ethanol Files) |
| TTE720 Turbochargers | Required | Required |
| 4 Bar MAP Sensors | Required | Required |
| RS+ Injector Upgrade Kit | Not Compatible | Required |
| 5W-40 Oil VW 502 00 / 505 00* | Required | Required |
| Brisk 2MOER08IR Racing Spark Plugs* | Required | Required |
| 034Motorsport M11 Head Studs | Recommended (for Ethanol Files) | Recommended (for Ethanol Files) |
| Stage 3 TCU | Required | Required |
-
5W-40 Oil VW 502 00 / 505 00
- Recommended Oil Change Interval: 5,000 - 6,500 Miles
-
Brisk 2MOER08IR Racing Spark Plugs
- Recommended Service Interval: 5,000 - 15,000 Miles Depending on Usage
- Recommended Plug Gap: .015" - .023" (Verify Before Installing)
EMISSIONS DISCLAIMER
- This product is sold for racing use as well as use on vehicles not registered for on highway use.
- By purchasing this product, you understand that this product is sold for racing use as well as used on vehicles not registered for on highway use, and that it is not legal for use on highway or street vehicles.
